AD9985A
Write and
Hexadecimal
Read or
Default
Register
Address
Read-Only
Bits
Value
Name
Function
*1******
**0*****
***0****
****1***
*****1**
******1*
Bit 6—Clamp Polarity. Valid only with external clamp signal.
(Logic 0 = active high, Logic 1 selects active low.)
Bit 5—Coast Select. Logic 0 selects the COAST input pins to be used
for the PLL coast. Logic 1 selects Vsync to be used for the PLL coast.
Bit 4—Coast Polarity Override. (Logic 0 = polarity determined by
chip, Logic 1 = polarity set by Bit 3 in Register 0x0F.)
Bit 3—Coast Polarity. Selects polarity of external Coast signal
(Logic 0 = active low, Logic 1 = active high).
Bit 2—Seek Mode Override (Logic 1 = allow low power mode,
Logic 0 = disallow low power mode).
Bit 1—PWRDN. Full Chip Power-Down, Active Low (Logic 0 = full chip
power-down, Logic 1 = normal).
0x10
R/W
7:3
10111***
Sync-on-Green
Sync-on-Green Threshold. Sets the voltage level of the sync-on-
*****0**
******0*
*******0
Threshold
green slicer’s comparator.
Bit 2—Red Clamp Select. Logic 0 selects clamp to ground. Logic 1
selects clamp to midscale (voltage at Pin 37).
Bit 1—Green Clamp Select. Logic 0 selects clamp to ground. Logic 1
selects clamp to midscale (voltage at Pin 37).
Bit 0— Blue Clamp Select. Logic 0 selects clamp to ground. Logic 1
selects clamp to midscale (voltage at Pin 37).
0x11
R/W
7:0
00100000
Sync Separator
Sync Separator Threshold. Sets the number of internal 5 MHz clock
Threshold
periods the sync separator counts to before toggling high or low.
This should be set to some number greater than the maximum Hsync
or equalization pulse width.
0x12
R/W
7:0
00000000
Pre-Coast
Pre-Coast. Sets the number of Hsync periods that Coast becomes
active prior to Vsync.
0x13
R/W
7:0
00000000
Post-Coast
Post-Coast. Sets the number of Hsync periods that Coast stays active
following Vsync.
0x14
RO
7:0
Sync Detect
Bit 7—Hsync detect. It is set to Logic 1 if Hsync is present on the
analog interface; otherwise it is set to Logic 0.
Bit 6—AHS: Active Hsync. This bit indicates which analog Hsync is
being used (Logic 0 = Hsync input pin, Logic 1 = Hsync from
sync-on-green).
Bit 5—Input Hsync Polarity Detect (Logic 0 = active low,
Logic 1 = active high).
Bit 4—Vsync Detect. It is set to Logic 1 if Vsync is present on the
analog interface; otherwise it is set to Logic 0.
Bit 3—AVS: Active Vsync. This bit indicates which analog Vsync is
being used (Logic 0 = Vsync input pin, Logic 1 = Vsync from
sync separator).
Bit 2—Output Vsync Polarity Detect (Logic 0 = active low,
Logic 1 = active high).
Bit 1—Sync-on-Green Detect. It is set to Logic 1 if sync is present on
the green video input; otherwise it is set to 0.
Bit 0—Input Coast Polarity Detect (Logic 0 = active low,
Logic 1 = active high).
0x15
R/W
7:2
111111**
Reserved
Bits [7:2] Reserved for future use. Must be written to 111111 for
proper operation.
1
0
******1*
*******1
Output
Formats
Reserved
Bit 1—4:2:2 Output Formatting Mode (Logic 0 = 4:2:2 mode,
Logic 1= 4:4:4 mode).
Bit 0—Must be set to 0 for proper operation.
Rev. 0 | Page 18 of 32
